Advanced Install of Cytnx

Build/Install Cytnx from source

For advanced user who wish to build Cytnx from source, we provide cmake install.

Dependencies

Cytnx requires the following minimum dependencies:

  • cmake >=3.14

  • git

  • make

  • Boost v1.53+ [check_deleted, atomicadd, intrusive_ptr]

  • openblas (or mkl, see below)

  • gcc v13+ (recommand latest or equivalent clang on Mac/Linux with C++20 support) (required -std=c++20)

In addition, you might want to install the following optional dependencies if you want Cytnx to compile with features like openmp, mkl and/or CUDA support.

[Openmp]

  • openmp

[MKL]

  • intel mkl

[CUDA]

  • Nvidia cuda library v10+

  • Nvidia cuDNN library

  • Nvidia cuTensor library

  • Nvidia cuQuantum library

[Python API]

  • python >= 3.9

  • pybind11 >= 3.0.0

  • python-graphviz

  • graphviz

  • numpy

  • beartype

There are two methods how you can set-up all the dependencies before starting the build process:

  1. Using conda to install dependencies

  2. Directly install dependencies one-by-one via system package manager

Note

We recommend using conda to handle all the dependencies (including compiling tools). This is the simplest way as conda automatically resolves the whole path of each dependency, allowing cmake to automatically capture those.

How it works?

>> The conda-forge channel includes not only the Python package but also other pre-compiled libraries/compilers.

Option A. Using anaconda/conda to install dependencies

  1. Install anaconda/miniconda, setting the virtual environments

  • For Linux/WSL:

$conda config --add channels conda-forge
$conda create --name cytnx python=3.9 _openmp_mutex=*=*_llvm
$conda activate cytnx
$conda upgrade --all

  • For MacOS:

$conda config --add channels conda-forge
$conda create --name cytnx python=3.9 llvm-openmp
$conda activate cytnx
$conda upgrade --all

Note

  1. The python=3.9 indicates the Python version you want to use. Generally, Cytnx is tested with 3.9+. You can replace this with the version you want to use.

  2. The last line is updating all the libraries such that they are all dependent on the conda-forge channel.

  1. Install the following dependencies:

$conda install cmake make boost boost-cpp git compilers numpy openblas arpack pybind11 beartype arpack

Note

  1. This installation includes the compilers/linalg libraries provided by conda-forge, so the installation of compilers on system side is not required.

  2. Some packages may not be required, or additional packages need to be installed, depending on the compiling options. See below for further information. If mkl shall be used instead of openblas, use the following dpenedencies:

    $conda install cmake make boost boost-cpp git compilers numpy mkl mkl-include mkl-service arpack pybind11 libblas=*=*mkl beartype arpack

  3. After the installation, an automated test based on gtest and benchmark can be run. This option needs to be activated in the install script. In this case, gtest needs to be installed as well:

    $conda install gtest benchmark

Hint

Trouble shooting:

  1. Make sure conda-forge channel has the top priority. This should be assured by running

    $conda config --add channels conda-forge.

  2. Make sure that the conda channel priority is flexible or strict. This can be achieved by

    $conda config --set channel_priority strict

    or changing ~/.condarc accordingly. You can check if the packages are correctly installed from conda-forge by running $conda list and checking the Channels row.

  3. Make sure libblas=mkl (you can check using $conda list | grep libblas)

  1. In addition, if you want to have GPU support (compile with -DUSE_CUDA=on), then additional packages need to be installed:

$conda install -c nvidia cuda

If cutensor shall be used as well (compile option -DUSE_CUTENSOR=ON), then further install the following:

$conda install -c nvidia cutensor

Similarly, cuqauantum (compile option -DUSE_CUTENSOR=ON), requires:

$conda install -c nvidia cuquantum

Option B. Install dependencies via system package manager

You can also choose to install dependencies directly from the system package manager, but one needs to carefully resolve the dependency path for cmake to capture them successfully.

Warning

For MacOS, a standard brew install openblas will not work since it lacks lapacke.h wrapper support.

If you are using MacOS, please install intel mkl (free) instead.

For the Python API, we recommend installing Python using anaconda or miniconda.

Compiling process

Once you installed all the dependencies, it is time to start building the Cytnx source code.

Option A. Using cmake preset

We support the cmake-presets tool for building the library starting from version v1.1.0. You can find the configuration file in CMakePresets.json. For example, if you choose the openblas-cpu preset, use the following command to build:

$cmake --preset openblas-cpu
$cmake --build --preset openblas-cpu

Note

If you are using Visual Studio Code, you can also take advantage of the CMake Tools extension, which provides built-in support for selecting and running CMake presets directly from the editor.

Option B. Using cmake install

Note

Use Option B when you need a bare CMake install of the C++ library (e.g. to link other CMake projects against libcytnx from a system prefix). If you only want the Python API, install via pip instead – see Option C below. cmake --install no longer copies the cytnx/ Python sources into the install prefix; that path is handled by pip + scikit-build-core to avoid producing two competing copies of the package.

Please see the following steps for the standard cmake compiling process and all the compiling options:

  1. Create a build directory:

$mkdir build
$cd build

  1. Use cmake to automatically generate compiling files:

$cmake [option] <Cytnx repo directory>

The following are the available compiling option flags that you can specify in [option]:

options

default

description

-DCMAKE_INSTALL_PREFIX

/usr/local/cytnx

Install destination of the library

-DBUILD_PYTHON

ON

Compile and install Python API

-DUSE_MKL

OFF

Compile Cytnx with intel MKL lib. If =off, default link to openblas

-DUSE_OMP

ON

Compile with openmp acceleration If USE_MKL=on, USE_OMP is forced=on

-DUSE_CUDA

OFF

Compile with CUDA GPU support

-DUSE_HPTT

OFF

Accelerate tensor transpose with hptt

Additional options for HPTT if -DUSE_HPTT=on:

options

default

description

-DHPTT_ENABLE_FINE_TUNE

OFF

HPTT optimized with native hardware

-DHPTT_ENABLE_AVX

OFF

Compile HPTT with AVX instruction

-DHPTT_ENABLE_ARM

OFF

Compile HPTT with ARM arch.

-DHPTT_ENABLE_IBM

OFF

Compile HPTT with ppc64le arch

  1. Compile the code:

    $make

  2. Install to the target location:

    $make install

Option C. Install the Python API via pip (recommended for Python users)

If you only need to use Cytnx from Python, the simplest path is to let pip drive the build through scikit-build-core. From the repository root:

$ pip install .

or, for development (rebuilds incrementally and lets import cytnx resolve back to the source tree):

$ pip install --editable .

This installs cytnx into your active Python environment as a normal package, so import cytnx works without any sys.path manipulation. The same dependencies described above (compilers, BLAS/LAPACK, etc.) still need to be present; pip handles only the Python side.

Using Python API after self-build install

If you used Option C (pip install . or pip install --editable .), Cytnx is already importable – import cytnx just works inside the Python environment where you ran pip. Skip to the example below.

If you used Option A (Install.sh) or Option B (bare CMake install), the install prefix contains only the compiled extension and its support files, not the cytnx/ Python sources, so you cannot import cytnx from there directly. Re-run pip install --editable . from the repository root to make the Python API importable; the already-compiled artifacts will be reused.

Once cytnx is importable in your Python environment:

  • In Python:

1import cytnx
2
3A = cytnx.ones(4)
4print(A)

Output>>

Total elem: 4
type  : Double (Float64)
cytnx device: CPU
Shape : (4)
[1.00000e+00 1.00000e+00 1.00000e+00 1.00000e+00 ]

Using the C++ API after a self-build install

Cytnx no longer exposes __cpp_include__/__cpp_lib__ Python attributes to introspect the C++ headers and library paths – pip and conda installs don’t carry those files at all (see Option C above). To compile your own C++ code against Cytnx, use Option B (bare CMake install) and consume the installed package the standard CMake way:

find_package(Cytnx CONFIG REQUIRED PATHS ${CYTNX_ROOT})
target_link_libraries(your_target PRIVATE Cytnx::cytnx)

where CYTNX_ROOT is the -DCMAKE_INSTALL_PREFIX used for the Option B install. tests/downstream_find_package/ in the Cytnx repository is a minimal example of a project consuming Cytnx this way.

Build troubleshooting

Check Cytnx version

The current version of the library can be printed by:

  • In Python:

1print("Cytnx version = ", cytnx.__version__)

Generate API documentation

An API documentation can be generated from the source code of Cytnx by using doxygen. The generated documentation is accessible online as the API reference. To create it locally, make sure that doxygen is installed:

$conda install doxygen

Then, use doxygen in the Cytnx source code folder to generate the API documentation:

$doxygen docs.doxygen

The documentation is created in the folder docs/. You can open docs/html/index.html in your browser to access it.
